roduct Description
2~4~8″ Diameter Single Wafer / 25pcs Carrier Box – including Container/4inch square wafers cassette box
* This wafer container is designed for 4″ diameter wafers. It can prevent precision wafer or substrate from damage and contamination during shipping and storing.
* The additional advantage is quite convenient in the process of cleaning and assembling.
* Each complete set includes: container, cover and spring
* The wafer container is packed in 1000 class clean room and plastic bag
* Material made: PP (Polypropylene)
* Working Temperature: < 50oC
——————————————————————————————————————————————————
– This wafer container is designed for 1″,2″,3″,4″,5″,6″ diameter wafers. It can prevent precision wafer or substrate from damage and contamination during shipping and storing.
– The additional advantage is quite convenient in the process of cleaning and assembling.
– Each complete set includes: container, cover and spring
– The wafer container is packed in plastic bag
– Material: Polypropylene
1″,2”,3”,4”,5”,6”SINGLE WAFER CARRIER BOX are in stock
*DP-1 :33mm diameter,9mm height,suitable for 1 inch (25.4mm )wafer
*DP-2 :60mm diameter,12mm height,suitable for 2 inch (50.8mm )wafer
*DP-3: 87mm diameter,13mm height,suitable for 3 inch (76.2mm )wafer
*DP-4 :112mm diameter,15mm height,suitable for 4 inch (100mm )wafer
*DP-6 :165mm diameter,16mm height,suitable for 6 inch (153mm )wafer
*DP-2 :60mm diameter,12mm height,suitable for 2 inch (50.8mm )wafer
*DP-3: 87mm diameter,13mm height,suitable for 3 inch (76.2mm )wafer
*DP-4 :112mm diameter,15mm height,suitable for 4 inch (100mm )wafer
*DP-6 :165mm diameter,16mm height,suitable for 6 inch (153mm )wafer
Specification
|
item
|
value
|
|
Place of Origin
|
Shanghai
|
|
Brand Name
|
Huoying
|
|
Industrial Use
|
For Square Semiconductor Wafer Carrier
|
|
Custom Order
|
Accept
|
|
Plastic Type
|
PET/PVC/PP
|
|
Size
|
2inch*2inch; 3inch*3inch; 4inch*4inch
|
|
Type
|
25pcs Cassette Or Single Wafer Container
|
|
Application
|
For Square Semiconductor Wafer Carrier
|
|
Model Number
|
square wafers cassette
|
Packing & Delivery
