6 inch N-type SiC Substrate – Product Specification

A 6-inch N-type SiC substrate refers to a wafer of silicon carbide (SiC) crystal with specific properties. Here’s a breakdown of its key characteristics and significance:

1. Material: Silicon Carbide (SiC)

• Wide Bandgap Semiconductor (~3.2 eV for 4H-SiC): Enables high-temperature operation (>200°C), high voltage handling, and high thermal conductivity.

• High Breakdown Electric Field: ~10× higher than silicon, allowing thinner drift layers and higher power density.

• Thermal Conductivity: ~3× higher than silicon, improving heat dissipation.

2. Diameter: 6 inches (150 mm)

• Industry Transition: The shift from 4-inch (100 mm) to 6-inch substrates reduces manufacturing costs by increasing die yield per wafer (~2.25× more area).

• Adoption Status: Leading manufacturers (Wolfspeed, II-VI, SK Siltron) now mass-produce 6-inch wafers; 8-inch (200 mm) is in R&D/pilot lines.

3. Conductivity Type: N-type

• Dopant: Typically nitrogen (N), creating free electrons for current conduction.

• Resistivity: Ranges from 0.01–0.03 Ω·cm (low-resistivity for epitaxy) to ~0.02 Ω·cm (device-ready).

• Applications: Used as starting material for high-voltage diodes, MOSFETs, JFETs, and RF devices.

4. Polytype: 4H-SiC Dominance

• Structure: Hexagonal (4H) polytype is standard for power devices due to superior electron mobility and thermal stability over 6H or 3C-SiC.

5. Key Specifications

• Thickness: 350–500 μm (may be thinned post-fabrication).

• Micropipe Density (MPD): Historically critical; now < 1 cm⁻² in commercial wafers.

• Dislocation Defects:

  • Threading Screw Dislocations (TSD): < 500 cm⁻²

  • Basal Plane Dislocations (BPD): < 1,000 cm⁻²

• Surface Finish: Epitaxy-ready with Ra < 0.2 nm (CMP-polished).

6. Applications

• Power Electronics: EV inverters, fast chargers, industrial motor drives.

• RF Devices: 5G base stations, radar systems (benefiting from high electron saturation velocity).

• Harsh Environments: Aerospace, downhole drilling.

7. Market & Supply Chain

• Key Suppliers: Wolfspeed (Cree), Coherent (II-VI), SK Siltron, STMicroelectronics.

• Cost Trend: ~$800–$1,200/wafer (declining as yields improve).

• Challenges: Crystal growth defects, high-energy consumption during production.

Why 6-inch N-type Matters:

• Cost Reduction: Larger wafers → lower $/die → accelerated adoption in EVs/industrial systems.

• Performance: Enables 1.2–3.3 kV devices with higher efficiency vs. Si-based solutions.

Properties	Specification					Unit
	Z		P	R	D
Diameter	150± 0.25					mm
Thickness	350(-25, 25)					µm
Surface off-orientation	4.0° towards [11-20]± 0.5°
Primary flat location	Perpendicular to the [11-20]± 5°
Primary flat length	47.5 ± 1.5					mm
Edge Exclusion	3					mm
Warp	≤ 25	≤ 35	≤ 45	≤ 60		µm
Bow	± 10	± 15	± 25	± 40		µm
TTV	≤ 5	≤ 8	≤ 10	≤ 15		µm
Dislocation Density-EPD	≤ 4000	≤ 6000	≤ 8000	≤ 12000	No requirements	/cm2
Dislocation Density-TSD	≤ 200	≤ 300	≤ 500	≤ 800		/cm2
Dislocation Density-BPD	≤ 800	≤ 1000	≤ 1500	≤ 2000		/cm2
Micropipe Density	≤ 0.2	≤ 0.2	≤ 0.5	≤ 1		/cm2
Polytype by high intensity light	4H 100%			4H 98%	4H 97%	% area
Hexagon by high intensity light	None			≤1%	≤3%	% area
Resistivity	0.015-0.025		0.015-0.028	0.010-0.030		Ω·cm
Surface roughness（ Si face）	< 0.2					nm
Surface roughness（ C face）	< 1			< 2		nm
Cracks by high intensity light	none
Si surface scratches by high intensity light	none			≤3ea ，each ≤ 10mm
Cumulative scratches length (By 8520)	≤ 75	≤ 100	≤150	No requirements		mm
Edge chip	none
Edge Profile	SEMI M55-0817
Stains by high intensity light	none
Residual Metals Contamination (Al, Cr, Fe, Ni, Cu, K, Ti &Mn)	< 5E10	< 1E11
Packaging	Multi-wafer Cassette/Single-wafer box
